Introducing
Westland Lysander 2,540mm (100″) 30-35cc ARF
SPECIFICATION:
– Wingspan: 2,540mm (100in).
– Length: 1,600mm (63in).
– Weight: 6.8 – 7.1kg (14.96 – 15.62 lbs).
– Wing area: 68.6 dm2.
– Wing loading: 99.13g/dm2.
– Wing type: Naca Airfoil.
– Servo mount: 42mm x 21mm.
– Spinner : Alu. Anodized Spinner 44mm
– Gear type: Aluminium Hi-grade for main gear (included).
– Tail gear type: Oleo struts for tail gear (included).
Parts listing required (not included):
– Radio: 06 channels minimum.
– Servo: 08 Standard high torque servos.
– Engine: 30 – 35 cc gas.
– Motor: Brushless outrunner 2500 – 3200W, 250KV.
– Propeller: Suit with your engine.
Recommended Motor and Battery set up (not included):
– Motor: RIMFIRE.1.60.
– Lipo cell: 12 cells 4,000-5,500mAh.
– Receiver battery: 6V-7.4V 1200-2200mAh Lipo.
– ESC: 80-100A.
Feature
– Designed for compatibility with both GP and EP flight
– Bolt-on two-piece wing for easy transport and setup at the field
– Strong Light Weight Construction
– High-quality hardware package included
Colour chart
Not update…
Packing
BOX DIMENSION
– 1600mm X 450mm X 390mm (L x W x H)
